U 130/25 Ferrite U cores type U130/25

کاشکه kaschke

Favourites Add to favorites
Rating
5


Core factor 0/33mm¯¹
eff. magn. path length 315mm
eff. magn. cross section 950mm²
eff. magn. volume 299600mm³
weight 750gr

Sales Expert
Sales ExpertResistor & Impeder ferrite Section

shahab@radelectric.co

+98 9392036467

+98 2191099990

Description

Application

  • Power Transmission

  • Line Transformers for Producing the High Voltage

  • Ignition Transformers in the Automotive Industry





Similar Products
